Description
Ready-to-Ship Configuration — every ZDS280B and ZDS280C unit is verified against your site voltage before dispatch, with a pre-shipment test record and spare parts pack included in the crate.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | ZDS280B / ZDS280C |
| Product Type | Automatic Straight Line Edge Bander |
| Main Functions (ZDS280B) | Gluing, End Trimming, Fine Trimming, Buffing |
| Main Functions (ZDS280C) | Gluing, End Trimming, Fine Trimming, Scraping, Buffing |
| Panel Thickness Range | 10–55 mm |
| Edge Thickness Range | 0.4–3 mm |
| Feed Speed | 15 m/min |
| Min. Panel Width | 45 mm |
| Min. Panel Length | 80 mm |
| Rated Power | 7.5 kW |
| Working Pressure | 0.6–0.8 MPa |
| Voltage & Frequency | 380V 3-Phase (50Hz/60Hz confirmed per order) |
| Fuselage Structure | 14 mm high-strength steel plate, frame-type, high-temperature quenched |
| Conveyor Guide Rail | HT260 cast iron |
| Pneumatic System | Festo or AirTAC cylinders with magnetic switches |
| Electrical Components | Delixi/Chint contactors, Omron travel switches |
| Net Weight | 650 kg (ZDS280B) / 800 kg (ZDS280C) |
| Overall Dimensions (L×W×H) | 2300×700×1250 mm (ZDS280B) / 2800×700×1250 mm (ZDS280C) |
Application Suitability
| Application | Material or Output |
|---|---|
| Custom cabinet door edging | MDF and particleboard with PVC banding 0.4–2 mm |
| Wardrobe side panel finishing | Plywood panels up to 55 mm thick with veneer edge |
| Small-batch office furniture | Melamine-faced chipboard with ABS or PVC edging |
| Joinery workshop first automation | Solid wood panels requiring straight-line edge banding |
Why the Voltage Question Should Come Before the Price
An automatic edge banding machine in stock is only useful if it actually runs when it arrives. We have seen 380V 50Hz machines land in 60Hz markets and overheat within the first shift — a problem that surfaces only after the crate is opened and the conveyor motor trips its thermal protection. [NEED_CITE: voltage and frequency standards by export market]
Every ZDS280 order is matched to your local supply before it leaves the floor. We confirm voltage, phase, and frequency in writing, then include the electrical schematic and a signed voltage confirmation sheet with your shipping documents. No guessing at the control cabinet, no rewiring on-site, no commissioning delays caused by a mismatch that should have been caught weeks earlier.
Dispatch Timing for Workshop Buyers Who Cannot Wait
When a small cabinet shop loses its only edge bander to a spindle failure, production stops until a replacement arrives. The ZDS280 series is held as ready stock specifically for these situations. You place the order, we confirm your voltage and panel range, and the machine ships within a short lead window rather than entering a multi-week production queue. This automatic edge banding machine in stock model suits workshops that need equipment running within days, not months.
Single-Unit Ordering Without the Bulk Commitment
Most importers expect to fill a container before a factory will quote. The ZDS280 can be ordered as a single unit — whether you are a joinery workshop buying your first edge bander or a regional dealer evaluating a demo machine before committing to a larger shipment. Shipping options are quoted upfront so you know the landed cost before confirming. [NEED_CITE: typical LCL and FCL transit windows for woodworking machinery]
Reading the Spec Sheet Against Your Actual Panels
The 10–55 mm panel thickness range covers most MDF, plywood, and particleboard stock used in custom furniture. If your typical panel sits at the lower end — say 12 mm MDF for cabinet backs — the ZDS280B’s four-station setup (gluing, end trim, fine trim, buffing) handles the job without adding cost for a scraping station you will never use. For thicker shelving panels in 25–40 mm particleboard where PVC edge leaves a visible glue line, the ZDS280C adds a scraping station that removes the residue before buffing, delivering a cleaner finish straight off the conveyor. The 15 m/min feed speed is consistent across both models, driven by a customized conveyor motor with thermal protection so it does not cut out mid-run on a heavy batch. The HT260 cast iron guide rail maintains alignment under continuous daily loading, which matters when tolerance drift shows up as mismatched panels at the assembly bench.
What Happens When You Skip the Voltage Check
Workshops that order on price alone often discover the problem at commissioning. A 50Hz motor running on 60Hz supply spins faster than rated, overheating the conveyor drive within hours. Control transformers designed for one voltage range saturate on another, frying contactors. The ZDS280’s Delixi and Chint electrical components are rated for the confirmed supply, and the Omron travel switches are calibrated to the correct cycle timing. Skipping this step means paying for a service call before the first panel is edged. [NEED_CITE: CE machinery directive requirements for industrial equipment]
Why Buyers Source This Model Here
Every stocked ZDS280 goes through a pre-shipment run on actual panel material, and the test record is sent to you before dispatch — not filed away in a drawer. The four-stage quality check covers incoming material inspection, in-process assembly verification, finished-product testing, and a final pre-shipment run so the machine you receive matches the machine that left the factory. Pneumatic components are sourced from Festo or AirTAC, meaning replacement cylinders and magnetic switches are available through local industrial suppliers in most markets. Documentation arrives in your agreed language, so your operator reads the manual on day one rather than waiting for a translation. Spare parts lists and packing photographs are included so you can verify the crate contents against the manifest immediately on delivery.
Documentation & Verification
- Pre-shipment test record run on your specified panel thickness and edge material
- Electrical schematic with confirmed voltage and frequency stamped per order
- Operation and maintenance manual provided in buyer’s agreed language
- Spare parts list with part numbers for pneumatic and electrical consumables
- Packing photographs showing crate contents before the lid is closed
- Customs documentation package supporting your import clearance process
Installation, Commissioning & Support
- Requires a level concrete floor with 2300×700 mm minimum footprint for ZDS280B clearance
- Dedicated 380V three-phase circuit rated above 7.5 kW with earth leakage protection
- KD packing means on-site assembly of conveyor infeed and outfeed sections
- First-run parameter setup covers glue pot temperature, feed speed, and trim depth
- Consumable spare parts pack included in crate covers scrapers, buffing wheels, and fuses
- HT260 guide rail inspection and conveyor belt tension check at 500-hour service intervals
What We Need to Match You to the Right Unit
Tell us your typical panel material and thickness range so we confirm whether the ZDS280B or ZDS280C fits your output. Share your site voltage and frequency — we will return a written confirmation before any payment is processed. If you are evaluating this automatic edge banding machine in stock as a demo unit for resale, let us know your target market so we can advise on model mix and documentation language.
Frequently Asked Questions
Q: Which ZDS280 models are currently in stock and how fast can they ship?
A: Both the ZDS280B and ZDS280C are held as ready stock. Once your voltage and panel requirements are confirmed, the machine is prepared for dispatch within a short lead window. We provide the pre-shipment test record and packing photographs before the crate is sealed, so you know exactly what is shipping.
Q: How do you match the machine to my country’s electrical supply?
A: Before any ZDS280 leaves stock, we confirm your local voltage, phase configuration, and frequency in writing. The electrical components are set to your supply specification, and a voltage confirmation sheet plus electrical schematic travels with the machine. This prevents the commissioning failures that occur when a 50Hz unit is plugged into a 60Hz grid.
Q: Can I order a single unit, and what shipping options are available?
A: Single-unit orders are accepted without a minimum quantity requirement. We quote shipping options — including LCL for one machine or FCL if you are adding other equipment — with estimated transit times provided upfront. This suits workshops buying their first edge bander or dealers ordering a demo unit to evaluate.
Q: What documentation comes with the machine for customs and installation?
A: Each shipment includes a pre-shipment test record, electrical schematic with voltage confirmation, operation manual in your agreed language, spare parts list, packing photographs, and standard customs documentation. This package supports both import clearance and day-one commissioning without additional requests.
Q: How are spare parts handled if something needs replacing after installation?
A: The spare parts list included in the crate covers consumables like scraper blades, buffing wheels, and pneumatic components. Festo and AirTAC cylinders are available through industrial suppliers in most regions. For model-specific parts, we supply replacements with reference to your machine serial number.
