Description
Fast dispatch confirmed — every JL-1 unit is fully assembled, voltage-verified against your local grid, and ready to ship within days rather than weeks.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Type | Single Row Hinge Boring Machine |
| Rated Power | 1.5 kW |
| Voltage & Frequency | 380V/415V three-phase four-wire |
| Control System | Foot switch control |
| Overall Dimensions (L×W×H) | 70×56×145 cm |
| Net Weight | 55 kg |
| Drill Sizes | Large drill 35 mm, small drill 3 mm |
| Drilling Position Adjustment | Vertical and horizontal adjustable |
| Motor Type | Pure copper motor |
| Sliding Mechanism | Precision guide rails |
| Language Options | Chinese and English (customizable to Spanish or other languages) |
| Plug Options | EU, USA, AU, UK |
| Assembly State | Fully assembled |
Application Suitability
| Application | Material or Output |
|---|---|
| Cabinet door hinge cup drilling | MDF, particleboard, plywood |
| Wardrobe and door panel hinge boring | Solid wood panels, laminated boards |
| Loose leaf hinge hole opening | Plywood and particleboard cabinet components |
| Small-batch custom furniture production | Mixed panel substrates for bespoke joinery |
Why the Voltage Question Should Come Before the Price on a Single Row Hinge Boring Machine
Confirming local voltage and plug type before ordering is the single step that prevents weeks of downtime on arrival.
I once watched a cabinet factory in the Middle East lose three full production weeks because the multi-boring machine that showed up had a 380V nameplate while the workshop ran on 220V three-phase. A transformer was sourced locally, but the delay rippled through an entire project handover schedule. With compact equipment like the JL-1 Single Row Hinge Boring Machine in stock, the temptation is to order quickly — yet a two-minute conversation about your site voltage and frequency eliminates a problem that no amount of technical support can fix remotely [NEED_CITE: voltage and frequency standards by export market].
Ready Stock Means Your Hinge Boring Station Arrives Complete
When a workshop adds hinge boring capability, the last thing needed is a partial shipment waiting on back-ordered components. The JL-1 ships fully assembled with precision guide rails already fitted and both the 35 mm large drill and 3 mm small drill head installed. You receive a single row hinge boring machine that is bolted to position, plugged in, and cutting hinge cups on the first day it reaches your floor.
Dispatch Timing That Matches Your Project Schedule
For custom furniture makers and small cabinet workshops, production schedules rarely leave room for extended equipment lead times. This Single Row Hinge Boring Machine in stock is configured and tested before packing, so transit time becomes the only variable between order and operation. Multi-voltage options and region-specific plug types are confirmed at the point of order, removing the electrical compatibility guesswork that stalls commissioning on so many imported machines [NEED_CITE: CE machinery directive requirements for industrial equipment].
Reading the Specs That Matter for Hinge Boring Accuracy
The 35 mm large drill and 3 mm small drill combination covers the standard European hinge cup and its pilot screw holes in a single setup, eliminating the need to reposition the panel between operations. Vertical and horizontal drilling position adjustment lets you match the exact offset your hinge hardware requires, whether you are working with standard concealed hinges or specialized soft-close variants. The precision guide rail sliding mechanism keeps the drill head travel stable across repeated cycles, which is where hand-drilled hinge holes typically drift and cause door misalignment downstream. A pure copper motor rated at 1.5 kW provides continuous duty output without the thermal cutouts that interrupt production on underpowered units running long batches of cabinet doors.
What Happens When the Wrong Configuration Reaches Your Workshop
Ordering a hinge boring machine without specifying your panel thickness range or hinge offset requirements often surfaces only when the first test doors fail to close flush. A machine set up for 18 mm standard board cannot simply be recalibrated on-site for 25 mm wardrobe panels if the vertical travel was never specified at order stage. Operators forced to improvise with manual depth shims produce inconsistent hinge cup depths, and the resulting door sag complaints land on the furniture maker, not the machine supplier [NEED_CITE: typical hinge boring tolerance requirements for cabinet assembly].
Why Procuring This Machine Here Reduces Your Commissioning Risk
Voltage and plug type are confirmed in writing before production begins, backed by an electrical schematic matched to your local supply. The operation and maintenance manual arrives in your agreed language, so the operator reading it on day one is not translating technical terms from an unfamiliar script. A pre-shipment test record with packing photographs documents exactly what was verified and how the machine was secured for transit. Spare parts covering drill bits, guide rail components, and motor brushes ship alongside the unit, so consumable wear never becomes an excuse for unplanned downtime.
Documentation & Verification
- Electrical schematic confirming your site voltage and frequency before dispatch
- Factory test record drilling hinge cups on your specified panel thickness
- Operation manual translated into your workshop’s working language
- Spare parts list covering drill bits, guide rail wear parts, and motor brushes
- Packing photographs showing securing method before crate closure
Installation, Commissioning & Support
- Requires a level concrete floor section within the 70×56×145 cm footprint with no special foundation
- Dedicated three-phase circuit matching confirmed 380V/415V supply with correct plug type
- Arrives fully assembled — position, connect power, and run test holes on day one
- Foot switch control requires no software setup or parameter programming for standard hinge patterns
- Pure copper 1.5 kW motor needs periodic brush inspection per the included maintenance schedule
- Precision guide rails require light lubrication at intervals noted in the operation manual
Before You Request a Quote
Share the panel materials and thickness range you process most often, along with the hinge hardware brand and model you standardize on. Let us know your workshop voltage and frequency so the electrical configuration matches your supply on arrival. If you are integrating this station alongside an existing edge bander or sliding table saw, mention your current feed direction so we can advise on workshop placement.
